Plinth Beam | How to Construct Plinth Beam in a Right Way? | #BaatGharKi | UltraTech Cement

Is construction of a plinth beam necessary while building a home? Check out the steps to make a plinth beam and save your wall from cracks.

Plinth beam is an RCC structure placed between the walls and foundation of a home. Plinth beam provides even support to the walls of a home. If the #plinthbeam is not constructed right, there are chances that cracks might appear on the walls.

It is mandatory to construct a plinth beam in flood-prone areas. Without it, there is a risk of the weakening and collapsing of the walls. Lets understand the right way to construct a Plinth beam.

Normally concrete of minimum M20 grade is used in the construction of a plinth beam. The depth of the beam should be at least 200mm and the upper surface of the beam should be higher than that of the ground.

Before pouring concrete, the position of the shuttering should be fixed firmly. The steel rods should be given a covering of 25mm and proper compacting of the concrete should be done.

Always remember the proper curing of the beam is also very important.

Keep watching #BaatGharKi from UltraTech Cement to know more about home-building. UltraTech is India's No. 1 Cement†About UltraTech: UltraTech Cement Ltd.

is the largest manufacturer of grey cement, Ready Mix Concrete (RMC) and white cement in India. It is also one of the leading cement producers globally. UltraTech as a brand embodies 'strength', 'reliability' and 'innovation'.

Together, these attributes inspire engineers to stretch the limits of their imagination to create homes, buildings and structures that define the new India.

Plinth beam construction | Home Foundation | Home Building | Home Construction Tips Subscribe to our channel:



https://bit.ly/32SHGQ4 Know more about the UltraTech @



https://www.ultratechcement.com/ Like us on



Facebook: https://www.facebook.com/UltraTechCementLimited #plinthbeamsection #useofplinthbeam #buildingconstruction

supervision-en-plinth-beam

Supervising Work

Damp Proofing | How to Protect Your Home from Water Seepage? | #BaatGharKi | UltraTech | English

Did you know that water can also seep into your house from the ground up?

This can cause dampness in your home. #Dampproofing is an effective way to stop this from happening.

This is a layer of a mixture of concrete and a waterproofing agent like Crete Pro which is applied on the foundation before the walls are built. This layer is 75mm or 3 inches in width.

This stops dampness from seeping upwards. Damp proofing course should always be out of reach of the water that can splash from the ground and it should be 30 cm above the highest level from the ground. These were the few important things about the damp proofing.

Keep watching #BaatGharKi from UltraTech Cement to know more about home-building. “UltraTech is India’s No. 1 Cement†About UltraTech: UltraTech Cement Ltd.

is the largest manufacturer of grey cement, Ready Mix Concrete (RMC) and white cement in India. It is also one of the leading cement producers globally. UltraTech as a brand embodies 'strength', 'reliability' and 'innovation'.

Together, these attributes inspire engineers to stretch the limits of their imagination to create homes, buildings and structures that define the new India. Water Seepage Treatment | Damp Proofing | Home Building Tips Subscribe to our channel:



https://bit.ly/32SHGQ4 Know more about the UltraTech @



https://www.ultratechcement.com/ Like us on



Facebook: https://www.facebook.com/UltraTechCementLimited #waterseepage #waterseepagesolution #seepageproblem

planning-and-supervision-en-damp-proofing

Supervising Work

RCC Footing Tips | Right Way to Install Trapezoidal RCC Footing | #BaatGharKi | UltraTech | English

A reinforced cement concrete footing bears the weight of your whole home. Footing precisely transfers the weight of your home to the ground. Let’s understand some important things about #RCCfootings.

Footing can be of trapezoidal, block or step-shaped according to the need of the structure. Before constructing footing, always ram the excavated ground and cover it with 150 mm thick concrete bed.

This will give you a plain ground for your footing, then fix your reinforcement cage with the right alignment and in the right place. Pour concrete on the cement bed after applying a layer of cement slurry on it.

Use concrete according to the size of the foundation and use shuttering accordingly. Always ensure that the size of the foundation is similar to the structural drawing.

Don’t forget to cure. Curing is mandatory once the footing is set.

Keep watching #BaatGharKi from UltraTech Cement to know more about home-building. “UltraTech is India’s No. 1 Cement†About UltraTech: UltraTech Cement Ltd. is the largest manufacturer of grey cement, Ready Mix Concrete (RMC) and white cement in India. It is also one of the leading cement producers globally.

UltraTech as a brand embodies 'strength', 'reliability' and 'innovation'. Together, these attributes inspire engineers to stretch the limits of their imagination to create homes, buildings and structures that define the new India. RCC Foundation | RCC Footing Installation | Trapezoidal Footing | Home Building Tips Subscribe to our channel:



https://bit.ly/32SHGQ4 Know more about the UltraTech @



https://www.ultratechcement.com/ Like us on



Facebook: https://www.facebook.com/UltraTechCementLimited #rccfoundation #reinforcedconcretefooting #homeconstructiontips

supervision-en-rcc-footing-tips

Supervising Work

Right Way of Concrete Finishing to Smoothen Concrete & Get Uniform Surface|#BaatGharKi | UltraTech

Concrete Finishing, strengthens concrete to concrete finishing to smoothen the concrete and get uniform surface. These are some tips on concrete finishing:

1. Concrete finishing gives concrete a smooth and even surface

2. Concrete finishing should be done after compacting

3. Dry cement should not be sprinkled on a wet concrete surface

4. Concrete finishing is done by screening, floating and trowelling the concrete For more information on #homebuilding ,

keep watching #BaatGharKi from UltraTech Cement. Learn more about other tips while home building here – https://www.ultratechcement.com/ “UltraTech is India’s No. 1 Cement†About UltraTech:

UltraTech Cement Ltd. is the largest manufacturer of grey cement, Ready Mix Concrete (RMC) and white cement in India.

It is also one of the leading cement producers globally. UltraTech as a brand embodies 'strength', 'reliability' and 'innovation'.

Together, these attributes inspire engineers to stretch the limits of their imagination to create homes, buildings and structures that define the new India. Concrete Finishing | Concrete Finishing Tips | Home Construction Tips | Smooth finish concrete Connect with Ultratech on:



Facebook - https://www.facebook.com/UltraTechCementLimited



Twitter - https://twitter.com/ultratechcement



LinkedIn - https://www.linkedin.com/company/ultratechcement/ #smoothfinishconcrete #ConcreteFinishing #ConcreteFinishingTips

supervision-en-right-way-of-concrete-finishing-to-smoothen-concrete-and-get-uniform-surface

Supervising Work

Concealed Piping Tips |Right Way to Conceal the Piping in the Walls | #BaatGharKi | UltraTech Cement

Concealed piping helps keep your home look neat and tidy. Lets understand the right way to conceal the piping in the walls of your home

1. Firstly, mark the outlets like the tap, shower head, washbasin and their pipe tracks on the wall with the help of a spirit level

2. Cut the marked area with the help of a disc blade and ensure the cut is 4-6mm more than the size of the pipes

3. Do not cut any beam or column in the process

4. Make grooves by digging the portion between the lines with a spade, and fit the pipes in grooves with the help of nails

5. Apply mortar and cement between the wall and pipes

6. To avoid cracks, use a steel mesh on the groove with the help of nails and mortar For more information on #homebuilding ,

keep watching #BaatGharKi from UltraTech Cement. Learn more about other tips while home building here https://www.ultratechcement.com/ “UltraTech is India's No. 1 Cement†About UltraTech: UltraTech Cement Ltd.

is the largest manufacturer of grey cement, Ready Mix Concrete (RMC) and white cement in India. It is also one of the leading cement producers globally. UltraTech as a brand embodies 'strength', 'reliability' and 'innovation'.

Together, these attributes inspire engineers to stretch the limits of their imagination to create homes, buildings and structures that define the new India.

House piping tips | Concealed piping |Home Construction Tips Connect with Ultratech on:



Facebook - https://www.facebook.com/UltraTechCementLimited



Twitter - https://twitter.com/ultratechcement



LinkedIn - https://www.linkedin.com/company/ultratechcement/ #housepipingtips #Concealedpiping #HomeConstruction

supervision-en-concealed-piping-tips

Supervising Work

Excavation for Foundation | How to Excavate a Foundation in a Right Way? | #BaatGharKi​ | UltraTech

Building a home? Wondering what will be the perfect excavation procedure for strong foundation of your home?

This video will help you to excavate a foundation in a right way. Excavation of a plot is done before laying the foundation for a home.

Foundation transfers the weight of your home’s structure to the strong soil below foundation. If the excavation work is not done in the right way, then the foundation laid is not strong enough which can cause cracks in the walls and pillars.

Let us know you the right way to do the #excavation for the foundation. Before excavation begins it is important to check whether the right layout of the foundation is marked on the plot. Check that the size, pattern, depth and slope of the excavation pits are even. Then pour water on excavation beds and start ramming it with hammers.

Fill the extra excavated areas with plum concrete. Always remember that there should not be any hollow spaces or soft spots. During deep excavations, support the sides with wooden structures so it won’t fall. The depth of excavation for a 2-3 story building should be about 1.5-2 metres.

This also depends on the quality and the strength of the soil. This is the right way to excavate while constructing your home. Important points: Excavation bed should be rammed after pouring water on it If the excavation is deep, support it with wooden planks Fill the extra excavated area with plum concrete

Keep watching #BaatGharKi from UltraTech Cement to know more about home-building. “UltraTech is India’s No. 1 Cement†About UltraTech: UltraTech Cement Ltd.

is the largest manufacturer of grey cement, Ready Mix Concrete (RMC) and white cement in India.

It is also one of the leading cement producers globally. UltraTech as a brand embodies 'strength', 'reliability' and 'innovation'.

Together, these attributes inspire engineers to stretch the limits of their imagination to create homes, buildings and structures that define the new India. Excavation | Excavation Procedure | Home Building | Home Construction Tips Subscribe to our channel:



https://bit.ly/32SHGQ4 Know more about the UltraTech @



https://www.ultratechcement.com/ Like us on



Facebook: https://www.facebook.com/UltraTechCementLimited #excavationforfoundation #excavationprocedureforfoundation #buildingconstruction #foundation

supervision-en-excavation-for-foundation

Supervising Work

How to Avoid Shrinkage Cracks | English | #BaatGharKi | #UltraTechCement

Shrinkage cracks can make your home weak and vulnerable. So below are the ways avoid Shrinkage cracks and to protect your home from them:

1. Always moisten the shuttering before pouring in the concrete and do not pour concrete while the shuttering is dry

2. Concrete placing should be done in the morning or the evening

3. While placing and setting the concrete, protect it from wind and harsh sunlight with the help of a tarpaulin

4. Don't let the moisture in the concrete dry. Curing should be done from time to time For more information on #homebuilding, keep watching #BaatGharKi from UltraTech Cement.

Learn more about other tips while home building here – https://www.ultratechcement.com/ “UltraTech is India’s No. 1 Cement†About UltraTech: UltraTech Cement Ltd.

is the largest manufacturer of grey cement, Ready Mix Concrete (RMC) and white cement in India.

It is also one of the leading cement producers globally. UltraTech as a brand embodies 'strength', 'reliability' and 'innovation'. Together, these attributes inspire engineers to stretch the limits of their imagination to create homes, buildings and structures that define the new India.

#HomeConstruction | #ShrinkageCracks |#HomeConstructionTips Connect with Ultratech on:



Facebook - https://www.facebook.com/UltraTechCementLimited



Twitter - https://twitter.com/ultratechcement



LinkedIn - https://www.linkedin.com/company/ultratechcement/

supervision-en-how-to-avoid-shrinkage-cracks

Supervising Work

How much water to mix with concrete? | English | #BaatGharKi | UltraTechCement

The strength and the quality of your concrete also depend on the water that was used while making it. Let’s understand more about the water that is used for mixing the concrete. Below are the 6 steps to building a concrete staircase: • Water chemically reacts with cement to make it stronger. • Normally drinking water is used while mixing concrete. • Avoid using saline water while mixing concrete because this can cause corrosion in the RCC steel rod. • Remember adding excess water to your concrete mixture can reduce the strength and durability of the concrete. • Extra water may lead to cracks in the concrete. • Always remember single UltraTech cement bag usually uses 20 to 27 litres of water So these were some simple tips on water and concrete ratio while constructing your house. Keep watching #BaatGharKi from UltraTech Cement to know more home-building tips. “UltraTech is India’s No. 1 Cement†About UltraTech: UltraTech Cement Ltd. is the largest manufacturer of grey cement, Ready Mix Concrete (RMC), and white cement in India. It is also one of the leading cement producers globally. UltraTech as a brand embodies 'strength', 'reliability', and 'innovation'. Together, these attributes inspire engineers to stretch the limits of their imagination to create homes, buildings, and structures that define the new India. Concrete | home construction | Home building tips | Build a house | Water and cement ratio Subscribe to our channel:

https://www.youtube.com/channel/UC7R0m2JO9EsJNJZPDR2U7YQ Know more about the UltraTech @ https://www.ultratechcement.com/ Like us on



Facebook: https://www.facebook.com/UltraTechCementLimited #Concrete #HomeConstruction #HomeBuildingTips #Buildahouse #WaterCementRatio

supervision-en-how-much-water-to-mix-with-concrete

Supervising Work

Types Of Soil And Its Affects On Foundation: Good Soil For Foundation | UltraTech Cement

"For a good and long-lasting foundation for a home, it needs good soil supporting it. Before starting with your home building process, one should be aware of theTypes Of Soil available and Its Effects On Foundation



This video show different soil and how they affect the foundation of your home. Watch this video now to know the best type of soil for the foundation.



What we have covered?



Introduction - 0:01

Types of Soil And Its Effects On Foundation - 0:10

Summary - 1:29



Learn more about other home building tips here - https://www.ultratechcement.com/solut...

House Building Materials - https://www.ultratechcement.com/produ...



Stay tuned to #BaatGharKi from UltraTech Cement to know more about home construction.

For more information on homebuilding visit: https://www.ultratechcement.com



UltraTech is India's No. 1 Cement. UltraTech Cement Limited is the largest manufacturer of Gray Cement, Ready Mix Concrete (RMC) and White Cement in India. It is one of the leading cement producers globally. UltraTech as a brand embodies 'Strength', 'Reliability' and 'Innovation'. Together, these characteristics inspire engineers to stretch the limits of their imagination to create the homes, buildings and structures that will define New India.



Home-building | Types of Soil for Foundation| Home Building Tips



Join UltraTech:

Subscribe to our channel: https://bit.ly/32SHGQ4



â–¶ â–¶ â–¶ Connect with UltraTech on â—€ â—€ â—€

✔ Facebook - https://www.facebook.com/UltraTechCem...

✔ Twitter - https://twitter.com/ultratechcement

✔ LinkedIn - https://www.linkedin.com/company/ultr...

Click here to see more such videos on homebuilding: https://www.youtube.com/playlist?list...



#TypesOfSoilForFoundation #homebuildingtips"""

planning-en-types-of-soil-and-its-affects-on-foundation-good-soil-for-foundation
